WHEEL LOADER SEM655D

SPECIFICATION

ADVANTAGE

Engine of SEM655D wheel loader
• WEICHAI WP6G125 diesel engine, 162kW @ 2200rpm, 6-cylinders, Tier II, turbocharged, water cooling
• Low speed engine with E-fan provides increased operating efficiency
• Enhanced fuel pre-filter eliminates water and contaminant from fuel for best fuel system protection
• 93% desert air cleaner to reduce earlier wearing and provide machine reliability even in the most severe applications
• The advanced cooling system provides high reliability in 50℃ ambient conditions with Shock pad mounts for reliability under severe applications. which can adapt all kinds of climate conditions with Large radiator for over 50℃ high temperature conditions and engine preheat for under -35℃ high cold conditions.
Transmission of SEM655D wheel loader
• Countershaft powershift transmission with upgraded core components provides high reliability
• F4R4 gear shifting is flexible and convenient
• Large rim-pull in 1st gear and higher speed in 2nd gear provide high efficiency for load and carry applications
• Clutch cutoff selection switch ensures stable and safe operation
• Torque convertor structure is simple and efficiency is high
• The SEM designed and built axle provides best in class performance in heavy duty applications
Applications of SEM655D wheel loader
• large volume earthmoving applications, Hopper feeding and Coal loading, Municipal, Construction, Mining, Forestry, Road, Railway, Port,Landscaping, building, sewer/water in, local construction, Ready mix cement, concrete products, quarry/stone, clay, recycled aggregate, sand and gravel, Highway, street, tunnel, airport, residential commercial.
Work tools of SEM655D wheel loader
• Multiple work tools are available for increased versatility
Hydraulic system of SEM655D wheel loader
• Twin pump flow merging hydraulic system for lower fuel consumption and big tractive force and larger breakout force for higher productivity. The displacement of working pump can reach 112 cc for higher efficiency
• The optimized hydraulic system paired with the drive train reduces machine cycle time and increases productivity
• Joystick hydraulic control for easy and precise operation
Cabin of SEM655D wheel loader
• Enlarged all-view cabin with Sliding side window and AC with fresh air circulation provide operator comfort
• Adjustable suspension seat with armrest and safety belt
• Joystick hydraulic control for easy and precise operation
Structure of SEM655D wheel loader
• Structures undergo Finite Element Analysis (FEA) and On Machine Stress Analysis (OMSA) to ensure durability
• Performance Series (PS) buckets improve loading capability
Safety of SEM655D wheel loader
• Caterpillar Production System (CPS) leveraged in manufacturing process
• 3-point touching design provides convenient operator entering to cabin
• Backup alarm ensures machine safety
• Environmentally friendly painting process
